DSKH Metering Devices
The durable, galvanized steel DSKH metering devices are designed for dual-line systems with pressures of up to 400 bar (5 800 psi). These metering devices are available with up to eight outlets, and each pair of outlets is equipped with an indicator pin for visual monitoring. Also, the DSKH metering devices are available with low-wear proximity switches, or piston detectors, for electrical monitoring. Additional features include rust-resistant material.
Technical Information of DSKH Metering Devices
| Outlets | 2~8 |
| Each Outlet Discharge Volume | Adjustable Discharge: 0~1.5 ml/cycle；Fixed Discharge: 0.3, 0.6, 1.2, 1.5 ml/cycle |
| Max.pressure | Max 40MPa |
| Operating temperature | Max120℃ |
| Material | Carbonsteel or SS |
Characteristics of DSKH Metering Devices
Easy to install.
Can be equipped with a mechanical indicator rod or electronic sensor for visual monitoring.
The valve body material is not only rust-resistant but also acid-resistant.
Cisolube offer custom lubrication pumps with a wide selection, Contact now!
